Immersion heater - 3000 W variable control

Immersion heater – 3000 W variable control
Immersion heater – 3000 W variable control
[Translate to Englisch:]
[Translate to Englisch:]

Immersion heater – 3000 W variable control

Icon Energy management, Power-to-Heat

The EHS-R immersion heater (included with the ATON) can be controlled directly by the freely programmable controllers (UVR16x2, UVR610, ...) via PWM, with a variable output from 50 W to 3000 W. The immersion heater sends the sensor values back to the CAN-EZ3 for further utilisation or forwarding to the CAN bus or DL bus.

Icon CORA-FIcon CORA-DLIcon InputsIcon Interfaces

3 Inputs

  • 2 sensor inputs PT1000
  • 1 PWM input 0-100% if not CORA-controlled

Interfaces:

  • CORA-F (wireless)
  • CORA-DL (wired)

total length of immersion heater: 410 mm
screw thread: 1 1/2"

TAPPS2

The TAPPS2 programming and planning software enables the creation of a logic diagram and the parameterisation of all x2 units (and the UVR1611).

Linux:

Two methods of installation are supported:

  • Debian package (.deb) (e.g., Debian, Ubuntu, Mint)
  • RPM package (.rpm) (e.g., Fedora, openSUSE, Mageia)

For both methods, a menu entry is added to GNOME or the KDE menu, with which the program can be launched. Root authorization is required for installation.

Debian package

The package can be installed simply by double clicking it in the file manager. If this is not possible, the installation can be done using the command line program dpkg in a terminal window:

dpkg -i tapps2-1.12-amd64.deb

Root authorization is required for the installation. For this, either simply enter su before executing the command, followed by the respective password query, or prefix the command sudo and enter the password when queried.

RPM package

The package can be installed simply by double clicking it in the file manager. If this is not possible, the installation can be done using the command line program rpm in a terminal window:

rpm -i tapps2-1.12-x86_64.rpm

To update the program (when an older version is already installed), -u should be use instead of -i.

Root authorization is required for the installation. For this, either simply enter su before executing the command, followed by the respective password query, or prefix the command sudo and enter the password when queried.

B2B Sales

Professionals can order by e-mail, stating their customer number.

Use in fresh water tanks

We expressly advise against using our heating rods in drinking water storage tanks! The heating rod is intended for installation in buffer storage tanks in which heating water is circulating.

Due to galvanic reactivity, the immersion heaters are not suitable for installation in DHW cylinders. Install in such cylinders at own risk. This requires specific, standardized measures and frequent inspection (e.g., of the sacrificial anode).

We do not offer any guarantee or warranty in case of calcification and galvanic corrosion!
