Immersion heater - 3000 W

Immersion heater - 3000 W

The EHS immersion heater switches the heating output in 750 W stages. In conjunction with the controlled EHS-R immersion heater or ATON, it is possible to arrange cascades economically. In the process, the EHS-R always performs the fine adjustment, which enables variable control of the output to be achieved.

Price group 2

01/EHSImmersion heater - 3000 W € 314,00
excl. 20% VAT

3 Inputs

2 sensor inputs PT1000
1 PWM input (in steps of 25%) if not wireless-controlled

Interfaces:

wireless

total length of immersion heater: 410 mm
screw thread: 1 1/2"

The immersion heater is eligible for use in drinking water environments, but eligibility for installation in cylinders for DHW or drinking water is limited by galvanic reactions. Refer to manual for details.

pdf Manual EHS / EHS-R Version 1.08 , 1 MB

pdf Manual EHS / EHS-R Version 1.04 , 867 KB

pdf Manual EHS Version 1.04 , 877 KB

pdf Manual EHS Version 1.04 , 885 KB

pdf Manual EHS Version 1.04 , 877 KB

EHS / EHS-R Firmware

Version 1.08 50 KB

F-Editor

The program F-Editor allows you to create and edit the configuration of the equipment CAN-MT, CAN I/O, CAN-BC, CAN-EZ and BL-NET. These newly created or edited data can then be transferred to the device with the Memory Manager and the Bootloader.

v1.12 1 MB
